Technical Specifications |
|
Model |
M-1325AT |
| XY area(mm) |
1300 x 2500 |
| Z area(mm) |
200 |
| Frame structure |
Welded with Steel Square Tubes |
| XY Guide |
Rack and Pinion, Gear drive and Linear Guide |
| Z Guide |
Ball screw drive and Linear Guide |
| X,Y,Z repositioning positioning accuracy |
± 0.05mm |
| Drive type |
Servo motor |
| Resolution |
0.025mm |
| Operating system |
Syntec |
| Spindle |
8.0KW HSD Air cooling |
| Max Speed |
60.000 mm/Min |
| Max Cutting Speed |
25,000 mm/Min |
| Auto Tools Changer |
Standard configure 8pcs tools
(optional:
10,12pcs) |
| Software |
Ucancam, Type3, Artcam (Optional) |
| Command code |
HPGL, G code |
| Collets |
3.175mm/6mm/12.7mm |
| Power |
AC380V± 10% /
50~60Hz / 3Phase |
|
|
